The Perfect Weld Is Just A Call Away.

Welcome to Rheton Welding Services Inc.

We offer a wide range of welding and fabricating services from our location in Beaverlodge, Alberta. Browse our complete listing of services in the "Services" section. To see images of selected projects we've completed in the past, visit the "Photo Gallery".

If you have any questions or want to get in touch, please use the information available on the "Contact" page.

Request A Quote

Fill out the form below and we will get in touch within 24 hours.

About Us

Leading welding and fabrication expert.

Rheton Welding Services Ltd. is a welding and fabricating company in Beaverlodge, Alberta, Canada, owned and operated by Richard Lappenbush.

We pride ourselves on being able to manufacture almost anything from Aluminum, Stainless Steel or Iron. From plain aluminum toolboxes to ornamental iron candelabras and furniture, we have the capabilities to do it all. "Contact" Rheton Welding today to discover what we can create for you.

Our Services

Expert Welding Solutions

From simple iron gate repairs to clean piping implementation for restaurants, Rheton Welding Service is the premier welder and fabricator in the surrounding area. See more to the below.

30 Gallon Mobile Fuel Tank (142L)

55×8.5x20H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 12 gauge steel – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

44 Gallon Mobile Fuel Tank (195L)

36x18x18H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 10 gauge steel – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

100 Gallon Mobile Fuel Tank (429L)

48x24x24H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 10 gauge steel – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

150 Gallon Mobile Fuel Tank (675L)

53x32x25H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 3/16 Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

200 Gallon Mobile Fuel Tank (910L)

60x36x28H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 3/16 Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

250 Gallon Mobile Fuel Tank (1121L)

58×38.5x34H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 3/16 Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

330 Gallon Mobile Fuel Tank (1470L)

62x42x37H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 3/16 Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

500 Gallon Mobile Fuel Tank (2240L)

72x48x42H

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 3/16 Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction line with a 2″ – 150# bronze gate valve for pump mounting.
  • Welded on tie down angles for easy installation.
  • UN 31A Certification Plate.
  • Painted with a high grade Industrial Enamel.

1000 Gallon Mobile Fuel Tank (4480L)

84x72Hx48W

  • Manufactured to meet Transport Canada CAN/CGSB 43.146-2016
  • 1/4 Mild Steel Plate – baffle construction.
  • High flow five in one fusible fill cap 3″.
  • 1″ suction/return line with ball valve.
  • Welded on tie down angles for easy installation.
  • UN 31AW Certification Plate.
  • Painted with a high grade Industrial Enamel.
  • 16″ manway for internal inspection.
  • 2″ clean out plug

Rheton Welding can manufacture almost anything once given a blueprint or just a great idea sketched on paper. From plain toolboxes to the more designed to accommodate any profession, we have the capabilities to do it all.

Rheton Welding also has the capabilities of designing and manufacturing custom iron products. From fences to candelabras to furniture. Whatever design you give us, we can produce.
